Incoloy is a nickel ferrochrome alloy designed for oxidation and
carbonation at elevated temperatures.Incoloy alloy has many kinds:
common such as Incoloy800, Incoloy800H, Incoloy800HT, Incoloy825,
Incoloy840, Incoloy901, Incoloy925, Incoloy20, Incoloy330, Incoloy
25-6mo, etc.The alloy contains a small amount of the metallic
elements molybdenum and copper.In reductive acid and oxidizing
acid, it has good corrosion resistance, as well as good resistance
to stress corrosion cracking, pitting and crevice corrosion.It has
excellent corrosion resistance to sulfuric acid and phosphoric
acid.The alloy has good cold and hot working properties and is easy
to be formed and welded.The main products of this alloy are rods,
tubes, plates, strips, wires and forgings, etc. It is mainly used
in the chemical, petrochemical, nuclear and rare metal refining
industries.
Invar 36 alloy overview:Invar 36 alloy is a special low expansion iron-nickel alloy with an
ultra-low expansion coefficient. Among them, the control of carbon
and manganese components is very important. Cold deformation can
reduce the coefficient of thermal expansion, and heat treatment in
a specific temperature range can stabilize the coefficient of
thermal expansion. Invar 36 is corrosion resistant in dry air at
room temperature. Corrosion (rusting) may occur in other harsh
environments, such as humid air.US grade: Invar36 Unipsan36 low expansion alloy British grade:
Invar N 25-20-7 French grade: Fe-Ni36 German grade: W.Nr.1.3912
Available product forms:
Pipes, pipes, fittings, flanges, sheets, strips, plates, round
bars, flat bars, fasteners, forgings, hexagons and wires UNS
K93600, UNS K93603 Werkstoff 1.3912 European Standard 1.3912
American Material Testing Standard F 1684 - 06
Complete specifications, stock in stock
Strip, sheet (thick plate, medium plate, sheet, steel plate), bar
(black bar, light bar, grinding bar, round bar, square bar, steel
bar), pipe (capillary, seamless pipe, steel pipe), Forgings
(flanges, elbows, bolts, nuts, tees), welding consumables (welding
rods, welding wire, welded pipes), wire and other materials.
Chemical Composition Of Invar 36
| C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr≤ | Ni≥ | Mo≥ | Cu≤ | Fe≤ | Co≤ |
| 0.03 | 0.20 | 0.35 | 0.02 | 0.01 | 0.20 | 35.0-37.0 | - | - | Re | 0.50 |
Invar 36 physical properties:
1, Invar36 density, density: ρ = 8.1g / cm3.
2. Invar36 melting temperature range, melting temperature range:
1430 °C.
3, Invar36 Curie temperature, Curie temperature: 230 °C.
4, Invar36 specific heat, specific heat: 515J / Kg.
Invar 36 welding:
Invar 36 can be welded using all welding processes, including
tungsten electrode welding, metal arc welding, plasma welding,
argon arc welding, and manual arc welding. First consider pulsed
arc welding. Before welding, the material should be in an annealed
state, clean, free of oil, scratches, marking paint, etc. Low heat
input must be used and the interlayer temperature should be below
120 °C. No pre-weld and post-weld heat treatment is required.
Invar36 Recommended Soldering Materials If the weld bead
performance is designed to be the same as the parent metal, an
electrode of the same material as the parent metal is required.
Welding wire: ERNiCr-3, welding rod: EniCrFe-3.
Invar 36 has the following features:
(1) It has an extremely low coefficient of thermal expansion
between -250 ° C and +200 ° C.
(2) Good plasticity and toughness.
Specifications
| Product Name | Invar36 K93600 1.3912 nickel base alloy bar pipe plate wire coil |
| Production Process | Cold Drawn,Cold Rolled,Hot Rolled,Bright Anneal etc |
| Size | 5.5-110mm(Hot rolled), 2-50mm(Cold drawn),110-500mm(Forged) |
| Standard | ASTM EN DIN GB ISO JIS |
| Tolerance | +/-0.05 ~+/0.02 |
Surface
| Pickling,Bright; No.1,2B,No.4,BA,8K
Satin,Brush,Hairline,Mirror,Polished
180 grits,320 grits,400 grits,600 grits,800 grits polished |
| Application | Constructions feilds and ship building industries
Petroleum,Chemical industries,War and electiciy industries. Food
processing and medical industries. Boiler heat cxchangers,Machinery
and hardware feilds. |
| Materials | Titanium alloy:TI-6AL-4V,TI-5AL-2.5SN,TA1,TA2,TA3,TA4,TA0,TC4 200series:201 202
300series:301,303Cu,304 304L 304H,304H,309S,310,310S,316
316L,316H,316Ti,321,347, 347H,330
400 series:
409L,410,410S,416F,420,420J1,420J2,430,431,440C,441,444,446,
600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D,
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS
S32760,2304,LDX2101.LDX2404,LDX4404,904L
Others: 153Ma,254SMo,253Ma,654SMo,F15,Invar36,1J22,N4,N6 etc
Alloy : Alloy 20, Alloy28, Alloy31;
Hastelloy: Hastelloy B, Hastelloy B-2,Hastelloy B-3,Hastelloy
C22,Hastelloy C-4,Hastelloy S,Hastelloy C276,Hastelloy C-2000,
Hastelloy G-35, Hastelloy G-30/X/N;
Haynes: Haynes 230, Haynes 556, Haynes 188;
Inconel: Inconel 100/600/601/602CA/617/625713/718738/X-750;
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90 ; |
Application areas:
(1) Production, storage and transportation of liquefied gas.
(2) Measurement and control instruments with operating temperatures
below +200 °C, such as temperature control devices.
(3) Screw connector bushings between metal and other materials.
(4) Bimetal and temperature controlled bimetal.
(5) Membrane frame.
(6) Shadow mask.
(7) Tempered mold for CRP parts of the aerospace industry.
(8) Frames of satellite and missile electronic control units below
-200 °C.
(9) Auxiliary electron tube in the electromagnetic lens of the
laser control device.
Invar 36 variety specifications and supply status:
1. Variety classification: Shanghai haosteel Co., Ltd. can produce
various specifications of Invar 36 seamless pipe, Invar 36 steel
plate, Invar 36 round steel, Invar 36 forgings, Invar 36 flange,
Invar 36 ring, Invar 36 welded pipe, Invar 36 Steel strip, Invar 36
wire and matching welding consumables.
2, delivery status: seamless pipe: solid solution + acid white,
length can be fixed; sheet: solid solution, pickling, trimming;
welded pipe: solid solution acid white + RT% flaw detection,
forgings: annealing + car light; The bar is in the state of
forging, surface polishing or car light; the strip is cold-rolled,
solid solution soft, and descaled; the wire is solid-dissolved and
acid-washed, or straight, solid solution Light state delivery.
